Lubrigard Custom Panel Unit 2HP 2GPM SPCL

When you need to install a permanent, continuous duty solution for your offline filtration, the PU-D Panel Unit is the perfect solution. Available in a variety of sizes, it will suit any space requirement you may have. These filtration systems have all the power needed for filtering oil viscosities up to 600cSt (ISO VG 680) at 100F within ambient temperature ranges of -15F to 150F. All Y2K products are 100% customizable upon request.

Typical Applications:

• Filtering contaminated system
• Collecting oil samples for analysis
• Dispensing new oil
• Permanent Installations

• Custom Panel Unit
• Single 50 PSI Bypass Filter Heads W/ Color Coded Differential Pressure Indicator
• 7 Micron Beta 2000 P1065
• 2HP 480V 3PH Exp Proof Motor
• *Motor comes not wired and without a switch or plug. Customer responsible for final wiring and safety check*
• 2GPM High Viscosity Pump
• Minimess Oil Sample Ports
• No Hoses
• Texture Black Powder Coat
• NOT AS SHOWN IN PHOTO - THIS SPEC ONLY HAS A SINGLE CANNISTER NOT DUAL
